Full 13 Dies AC Hydraulic Hose Crimping Machine SP32 For Excavator Repair Workshop

Place of Origin CN
Brand Name MENSION
Certification CE RoHS
Model Number MS-SP32
Minimum Order Quantity 1 Set
Price Contact Us
Packaging Details One Plywood For One Set
Delivery Time 2 - 7 Working Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000 Sets Per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Crimping Range 14 - 87mm Hose Size 1/4 - 2.5inch
Die Sets 13 Color Blue
Max. Opening 31mm Crimping Force 650T
Product Name SP32 AC Hose Crimping Machine Application Workshop
System Pressure 31.5Mpa Power 3.75KW
Size 650*550*1360mm Weight 310Kg
High Light

Safe AC Hose Crimping Machine

,

SP32 AC Hose Crimping Machine

,

SP32 ac hose crimper

Leave a Message
Product Description



WORKSHOP AC HOSE CRIMPING MACHINE SP32


DESCRIPTION



MS-SP32  ac hose crimper machine is the best choice for mass hose assembly producing. It is with 13 dies sets, suitable for hose from 1/4 inch to 2 1/2 inch crimping. The emergency stop device makes it more safe.



ADVANTAGES



1. Simple structure, easy maintenance;

2. Advanced diameter control device, high accurate;

3. Quick change and rack, improve the efficiency;

4. Large opening stroke.



TECHNICAL DATA



Model

MS-SP32 AC Hose Crimping Machine

Crimping Range

14 - 87 (mm)

Crimping Force

650 (T)

Hose Size

1/4 - 2.5 (inch)

Max. Opening

31 (mm)

Die Sets

13

Die Set Type

P32

System Pressure

31.5 (Mpa)

Accuracy

0.01 (mm)

Control

MS

Standard Voltage

220 (V) / 380 (V)

Motor Power

3.75 (KW)

Length

650 (mm)

Width

550 (mm)

Height

1360 (mm)

Weight

310 (KG)



Full 13 Dies AC Hydraulic Hose Crimping Machine SP32 For Excavator Repair Workshop 0



P32 CRIMPER MACHINE DIE SETS



Die No.

Crimping Range

Length

6*

6 - 8 mm

55

8*

8 - 10 mm

55

10*

10 - 12 mm

55

12*

12 - 14 mm

55

14

14 - 16 mm

55

16

16 - 19 mm

55

19

19 - 22 mm

55

22

22 - 26 mm

70

26

26 - 30 mm

70

30

30 - 34 mm

70

34

34 - 39 mm

75

39

39 - 45 mm

75

45

45 - 51 mm

90

51

51 - 57 mm

90

57

57 - 63 mm

100

63

63 - 69 mm

110

69

69 - 78 mm

110



NOTE



- * for non standard die sets;

- Customized die sets are available;

- Special voltage 110V, 208V, 240V, 415V are availbale;



Full 13 Dies AC Hydraulic Hose Crimping Machine SP32 For Excavator Repair Workshop 1



Full 13 Dies AC Hydraulic Hose Crimping Machine SP32 For Excavator Repair Workshop 2



Full 13 Dies AC Hydraulic Hose Crimping Machine SP32 For Excavator Repair Workshop 3
