Specifications
Highlight:
Light Weight Portable Hose Crimping Machine
,1 Inch Portable Hose Crimping Machine
,Light Weight portable hose crimper
Crimping Range:
14 - 45mm
Hose Size:
1/4 - 1inch
Die Sets:
7
Color:
Blue
Max. Opening:
20mm
Crimping Force:
150T
Product Name:
P16 Hose Processing Machine
Application:
Workshop
Oil Tank:
20L
Pressure:
28Mpa
Size:
400*320*300mm
Weight:
32Kg
Key Attributes
Brand Name:
MENSION
Model Number:
MS-P16
Place of Origin:
CN
Certification:
CE RoHS
Minimum Order Quantity:
1 Set
Price:
Contact Us
Supply Ability:
1000 Sets Per Month
Delivery Time:
2 - 7 Working Days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Standard Packaging:
One Plywood For One Set
Product Description
1 Inch Portable Hose Crimping Machine Industrial Pipe Pressing Tool
PORATBLE HYDRAULIC HOSE CRIMPING MACHINE P16
Description
With the P16 portable manual hose crimping machine, professionals in various industries can confidently tackle hydraulic, industrial, or automotive hose assembly tasks on-site. Its compact size and ease of use make it the go-to choice for mobile technicians, field service professionals, and anyone in need of a portable hose crimping solution. Say goodbye to the limitations of traditional crimping machines and embrace the freedom and efficiency of the small size hose pressing tool. Elevate your on-site hose assembly capabilities with precision and convenience like never before.
Technical Data
| Model | P16 Manual Crimping Machine |
|---|---|
| Crimping Range | 14 - 47 (mm) |
| Crimping Force | 150 (T) |
| Hose Size | 1/4 - 1 (inch) |
| Max. Opening | 20 (mm) |
| Die Sets | 7 |
| Die Set Type | P16 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | MS |
| Standard Voltage | Manual Pump |
| Motor Power | Manual Pump |
| Length | 400 (mm) |
| Width | 320 (mm) |
| Height | 300 (mm) |
| Weight | 32 (KG) |
P16 Hose Pressing Machine Die Sets
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8 mm | 55 |
| 8* | 8 - 10 mm | 55 |
| 10* | 10 - 12 mm | 55 |
| 12* | 12 - 14 mm | 55 |
| 14 | 14 - 16 mm | 55 |
| 16 | 16 - 19 mm | 55 |
| 19 | 19 - 23 mm | 55 |
| 23 | 23 - 27 mm | 55 |
| 27 | 27 - 31 mm | 55 |
| 31 | 31 - 35 mm | 65 |
| 35 | 35 - 41 mm | 65 |
Note
- * for non standard die sets
- Customized die sets are available
- Max. opening is the stroke between die sets fully closed and fully opened
Optional
- Quick Change Tool
- Quick Change Die Set Rack
- UC control
P16 Hydraulic Crimping Machine Applications
Overall Rating
5 star
100%
4 star
0
3 star
0
2 star
0
1 star
0
All Reviews
-
AUsed this P16 crimper daily for months. No leaks, no failures, crimps hold great under high pressure. Perfect for small-batch assembly and emergency repairs.
-
SI've been running a hardware store for three years. This hydraulic crimping machine was the one I chose after comparing five different models. Initially, I was worried about the precision, so I tested over 20 high-pressure oil pipe connectors—each crimped perfectly in one go without any leaks. Now, customer feedback is great, and the repeat purchase rate is high
-
AThose who open a truck repair shop usually apply pressure to the brake oil pipe and hydraulic oil pipe of the truck. The manual version has sufficient pressure and the joint is tightly pressed. The truck runs long distances without oil leakage, which is recognized by the driver. The machine is durable and can be used in stores, as well as in places without electricity outdoors
