Specifications
Highlight:
4 Layers Hose Crimping Machine
,Rubber Hose Crimping Machine
,2 Inch Hose Crimping Machine
Crimping Range:
14 - 87mm
Hose Size:
0.5in - 2.5in
Die Sets:
13
Color:
Blue
Max. Opening:
31mm
Crimping Force:
650T
System Pressure:
31.5Mpa
Voltage:
380V 60HZ
Size:
650*550*1360mm
Weight:
310Kg
Key Attributes
Brand Name:
MENSION
Model Number:
P32NC
Place of Origin:
CN
Certification:
CE RoHS TUV
Minimum Order Quantity:
1 Set
Price:
Contact Us
Supply Ability:
1000 Sets Per Month
Delivery Time:
2 - 7 Working Days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Standard Packaging:
One Plywood For One Set
Product Description
FAMOUS P32NC HYDRAULIC HOSE CRIMPING MACHINE
The P32NC pipe pressing machine, also known as MS-NC130 in local markets, is engineered for crimping high-pressure rubber hose assemblies ranging from 0.5 inches to 2.5 inches. This advanced hydraulic hose crimper features a sophisticated numerical control system and incorporates a crucial pressure hold function. Unlike conventional machines, the P32NC maintains pressure for several seconds after die closure, significantly enhancing the quality and reliability of hose fitting assemblies.
With integrated CNC technology, this crimping machine offers intelligent operation and exceptional convenience, making it suitable for both experienced operators and new users. The system automatically stores crimping data for identical hose sizes, making it particularly efficient for high-volume hydraulic hose production facilities.
KEY ADVANTAGES
- Ergonomic design optimized for high operational efficiency
- Quick-change tool system supporting 13 different die sets
- Emergency stop safety device to prevent operator injury
- Premium quality spare parts for extended machine lifespan
- Advanced material processing technology
TECHNICAL SPECIFICATIONS
| Model | P32NC Hose Crimping Machine |
|---|---|
| Crimping Range | 14 - 87 mm |
| Crimping Force | 650 Tons |
| Hose Size | 0.5 - 2.5 inches |
| Maximum Opening | 31 mm |
| Die Sets | 13 |
| Die Set Type | P32 |
| System Pressure | 31.5 MPa |
| Accuracy | 0.01 mm |
| Control System | UC-Automatic Control |
| Standard Voltage | 380V or 220V |
| Motor Power | 3.75 KW |
| Length | 650 mm |
| Width | 550 mm |
| Height | 1360 mm |
| Weight | 310 KG |
P32NC CRIMPER DIE SETS SPECIFICATIONS
| Die Number | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8 mm | 55 mm |
| 8* | 8 - 10 mm | 55 mm |
| 10* | 10 - 12 mm | 55 mm |
| 12* | 12 - 14 mm | 55 mm |
| 14 | 14 - 16 mm | 55 mm |
| 16 | 16 - 19 mm | 55 mm |
| 19 | 19 - 22 mm | 55 mm |
| 22 | 22 - 26 mm | 70 mm |
| 26 | 26 - 30 mm | 70 mm |
| 30 | 30 - 34 mm | 70 mm |
| 34 | 34 - 39 mm | 75 mm |
| 39 | 39 - 45 mm | 75 mm |
| 45 | 45 - 51 mm | 90 mm |
| 51 | 51 - 57 mm | 90 mm |
| 57 | 57 - 63 mm | 100 mm |
| 63 | 63 - 69 mm | 110 mm |
| 69 | 69 - 78 mm | 110 mm |
Important Notes:
- * indicates non-standard die sets
- Customized die sets with different sizes, shapes, or lengths are available upon request
- Special voltage configurations including 110V, 208V, 240V, and 415V are available
- * indicates non-standard die sets
- Customized die sets with different sizes, shapes, or lengths are available upon request
- Special voltage configurations including 110V, 208V, 240V, and 415V are available
