Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing

  • Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing
  • Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing
  • Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing
Place of Origin CN
Brand Name MENSION
Certification CE RoHS
Model Number MS-E130-I
Minimum Order Quantity 1 Set
Price Contact Us
Packaging Details One Plywood For One Set
Delivery Time 2 - 7 Working Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000 Sets Per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Crimping Range 14 - 87mm Hose Size 1/4 - 2.5inch
Die Sets 13 Color Blue
Max. Opening 31mm Crimping Force 650T
Product Name E130-I AC Hose Crimping Machine Application Workshop
System Pressure 31.5Mpa Power 3.75KW
Size 650*550*1360mm Weight 310Kg
High Light

Foot Pedal ac pipe crimping machine

,

E130-I ac pipe crimping machine

,

E130-I industrial hose crimper
Leave a Message
Product Description



INDUSTRIAL AC HOSE CRIMPING MACHINE MS-E130-I

DESCRIPTION



MS-E130-I high pressure hydraulic hose crimper is famous for its big crimping range ans low cost. It is the ideal choice when crimping large hose assemblies.



ADVANTAGES



1. Intergrated button, safe and convenient;

2. High quality motor, good heat dispation, long service life;

3. Quick die sets changing technology, improve the efficiency and productivity.

4. Die sets choosing reference sheet, easy to learn.



TECHNICAL DATA



Model

MS-E130-I AC Hose Crimping Machine

Crimping Range

14 - 87 (mm)

Crimping Force

650 (T)

Hose Size

1/4 - 2.5 (inch)

Max. Opening

31 (mm)

Die Sets

13

Die Set Type

P32

System Pressure

31.5 (Mpa)

Accuracy

0.01 (mm)

Control

MS

Standard Voltage

220 (V) / 380 (V)

Motor Power

3.75 (KW)

Length

650 (mm)

Width

550 (mm)

Height

1360 (mm)

Weight

310 (KG)



Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing 0

P32 HOSE CRIMPER DIE SETS



Die No.

Crimping Range

 Length

6*

6 - 8 mm

 55

8*

8 - 10 mm

 55

10*

10 - 12 mm

 55

12*

12 - 14 mm

 55

14

14 - 16 mm

 55

16

16 - 19 mm

 55

19

19 - 22 mm

 55

22

22 - 26 mm

 70

26

26 - 30 mm

 70

30

30 - 34 mm

 70

34

34 - 39 mm

 75

39

39 - 45 mm

 75

45

45 - 51 mm

 90

51

51 - 57 mm

 90

57

57 - 63 mm

 100

63

63 - 69 mm

 110

69

69 - 78 mm

 110



NOTE



- * for non standard die sets;

- Customized die sets are available;

- Special voltage 110V, 208V, 240V, 415V are availbale;



Hydraulic AC Pipe Crimping Machine E130 - I For Industrial Hose Pressing 1
