High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage

  • High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage
  • High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage
  • High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage
Place of Origin CN
Brand Name MENSION
Certification CE RoHS
Model Number MS-P150
Minimum Order Quantity 1 Set
Price Contact Us
Packaging Details One Plywood For One Set
Delivery Time 2 - 7 Working Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000 Sets Per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Crimping Range 14 - 87mm Hose Size 1/4 - 2 1/2inch
Die Sets 14 Color Grey And Orange
Max. Opening 61mm Crimping Force 380T
Product Name P150 Brake Hose Crimping Machine Application Production
System Pressure 31.5Mpa Power 3.75KW
Size 720*970*1600mm Weight 1020Kg
Highlight

High Pressure Brake Hose Crimping Machine

,

P150 Brake Hose Crimping Machine

,

P150 High Pressure Hose Crimping Machine
Leave a Message
Product Description



PRESSURE BRAKE HOSE CRIMPING MACHINE MS-P150

DESCRIPTION



MS-P150 is oue new hose crimping machine. It is with a thin crimping head, which is more suitable for crimping the bend fittings.



ADVANTAGES



1. Forged steel hydraulic cylinder, high hardness;

2. Famous PLC control system;

3. High precision.



TECHNICAL DATA



Model

MS-P150 Brake Hose Crimping Machine

Crimping Range

14 - 87 (mm)

Crimping Force

380 (T)

Hose Size

1/4 - 2 1/2 (inch)

Max. Opening

61 (mm)

Die Sets

14

Die Set Type

P150

System Pressure

31.5 (Mpa)

Accuracy

0.01 (mm)

Control

UC

Standard Voltage

220 (V) / 380 (V)

Motor Power

3.75 (KW)

Length

720 (mm)

Width

970 (mm)

Height

1600 (mm)

Weight

1020 (KG)



High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage 0



P150 CRIMPER DIE SETS



Die No.

Crimping Range

 Length

6*

6 - 8mm

 55

8*

8 - 10mm

 55

10*

10 - 12mm

 55

12*

12 - 14mm

 55

14

14 - 16mm

 55

16

16 - 19mm

 55

19

19 - 22mm

 55

22

22 - 26mm

 70

26

26 - 30mm

 70

30

30 - 34mm

 70

34

34 - 39mm

 75

39

39 - 45mm

 75

45

45 - 51mm

 90

51

51 - 57mm

 90

57

57 - 63mm

 100

63

63 - 69mm

 110

69

69 - 74mm

 110
74 74 - 80mm 110
78* 78 - 87mm 110



NOTE



- * for non standard die sets;

- Customized die sets are available;

- Special voltage 110V, 208V, 240V, 415V are availbale;



High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage 1



High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage 2



High Pressure Hose Crimping Tool Brake Hose Crimping Machine Hose Swage 3
