Specifications
Highlight:
14 - 87mm hydraulic rubber hose crimping machine
,2 1/2 Inch big pipe crimping machine
,1/4 inch rubber hose crimper
Crimping Range:
14 - 87mm
Hose Size:
1/4 - 2 1/2inch
Die Sets:
14
Color:
Grey And Orange
Max. Opening:
61mm
Crimping Force:
380T
Product Name:
P150 Rubber Hose Crimping Machine
Application:
Workshop
System Pressure:
31.5Mpa
Power:
3.75KW
Size:
720*970*1600mm
Weight:
1020Kg
Key Attributes
Brand Name:
MENSION
Model Number:
MS-P150
Place of Origin:
CN
Certification:
CE RoHS
Minimum Order Quantity:
1 Set
Price:
Contact Us
Supply Ability:
1000 Sets Per Month
Delivery Time:
2 - 7 Working Days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Standard Packaging:
One Plywood For One Set
Product Description
1/4 - 2 1/2 Inch Hydraulic Rubber Hose Crimping Machine
MS-P150 Rubber Hose Crimping Machine
Product Overview
The MS-P150 is our latest rubber hose crimping machine featuring a super thin crimping head that enables large bend fitting feeding. This machine is equipped with a die set quick change device, significantly improving productivity.
Key Advantages
- Intelligent CNC control system with stable performance
- High-speed operation
- Multifunctional foot pedal
- Super thin crimping head with advanced oil transfer channel
Technical Specifications
| Model | MS-P150 Rubber Hose Crimper |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 380 (T) |
| Hose Size | 1/4 - 2 1/2 (inch) |
| Max. Opening | 61 (mm) |
| Die Sets | 14 |
| Die Set Type | P150 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | UC |
| Standard Voltage | 220 (V) / 380 (V) |
| Motor Power | 3.75 (KW) |
| Length | 720 (mm) |
| Width | 970 (mm) |
| Height | 1600 (mm) |
| Weight | 1020 (KG) |
P150 Crimping Machine Die Sets
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8 mm | 55 |
| 8* | 8 - 10 mm | 55 |
| 10* | 10 - 12 mm | 55 |
| 12* | 12 - 14 mm | 55 |
| 14 | 14 - 16 mm | 55 |
| 16 | 16 - 19 mm | 55 |
| 19 | 19 - 22 mm | 55 |
| 22 | 22 - 26 mm | 70 |
| 26 | 26 - 30 mm | 70 |
| 30 | 30 - 34 mm | 70 |
| 34 | 34 - 39 mm | 75 |
| 39 | 39 - 45 mm | 75 |
| 45 | 45 - 51 mm | 90 |
| 51 | 51 - 57 mm | 90 |
| 57 | 57 - 63 mm | 100 |
| 63 | 63 - 69 mm | 110 |
| 69 | 69 - 74 mm | 110 |
| 74 | 74 - 80 mm | 110 |
| 78* | 78 - 87 mm | 110 |
Important Notes
- * indicates non-standard die sets
- Customized die sets are available
- Special voltages (110V, 208V, 240V, 415V) are available
