2.5 INCH PORTABLE HYDRAULIC HOSE CRIMPER MS-P150
DESCRIPTION
MS-P150 portable hydraulic hose crimping machine can be used easily for big bend fittings. The crimping unit is separated with the hydraulic drive unit, so crimping is more convenient.
ADVANTAGES
1. High quality mold steel Cr12Mov die sets, high hardness;
2. Quick die sets change and installation;
3. Advanced touchscreen operate, more intelligent.
TECHNICAL DATA
|
Model |
MS-P150 Portable Hydraulic Hose Crimper |
|
Crimping Range |
14 - 87 (mm) |
|
Crimping Force |
380 (T) |
|
Hose Size |
1/4 - 2 1/2 (inch) |
|
Max. Opening |
61 (mm) |
|
Die Sets |
14 |
|
Die Set Type |
P150 |
|
System Pressure |
31.5 (Mpa) |
|
Accuracy |
0.01 (mm) |
|
Control |
UC |
|
Standard Voltage |
220 (V) / 380 (V) |
|
Motor Power |
3.75 (KW) |
|
Length |
720 (mm) |
|
Width |
970 (mm) |
|
Height |
1600 (mm) |
|
Weight |
1020 (KG) |
P150 SERIES CRIMPER DIE SETS
|
Die No. |
Crimping Range |
Length |
|
6* |
6 - 8mm |
55 |
|
8* |
8 - 10mm |
55 |
|
10* |
10 - 12mm |
55 |
|
12* |
12 - 14mm |
55 |
|
14 |
14 - 16mm |
55 |
|
16 |
16 - 19mm |
55 |
|
19 |
19 - 22mm |
55 |
|
22 |
22 - 26mm |
70 |
|
26 |
26 - 30mm |
70 |
|
30 |
30 - 34mm |
70 |
|
34 |
34 - 39mm |
75 |
|
39 |
39 - 45mm |
75 |
|
45 |
45 - 51mm |
90 |
|
51 |
51 - 57mm |
90 |
|
57 |
57 - 63mm |
100 |
|
63 |
63 - 69mm |
110 |
|
69 |
69 - 74mm |
110 |
| 74 | 74 - 80mm | 110 |
| 78* | 78 - 87mm | 110 |
NOTE
- * for non standard die sets;
- Customized die sets are available;
- Special voltage 110V, 208V, 240V, 415V are availbale;
-
