Pipe Fitting Press Machine 1/4''
,P16HP Pipe Fitting Press Machine
,Manual P16HP Hydraulic Hose Crimping Machine
PORTABLE MANUAL HOSE PRESS P16MP
DESCRIPTION
In the realm of industrial equipment, precision and efficiency reign supreme. Introducing the game-changing 1-Inch Hose Crimping Machine, meticulously crafted to streamline hose assembly processes with unparalleled accuracy and reliability.
Engineered to accommodate hoses up to one inch in diameter, this innovative machine boasts a sleek design and intuitive interface, empowering operators to effortlessly navigate crimping operations. From automotive workshops to construction sites, its versatility knows no bounds.
Bid farewell to laborious manual crimping techniques and embrace the future of hose assembly technology. With the 1-Inch Hose Crimping Machine, expect nothing less than seamless operations and elevated productivity.
MAIN FEATURES
1. Portability:
Our manual 1-inch hose crimping machine is compact and lightweight, allowing you to carry it anywhere, ensuring convenience and flexibility in your work environment.
2. Precision Crimping:
Experience accurate and secure hose fittings every time. This machine is designed with precision in mind, ensuring that your crimps are reliable and leak-free, meeting industry standards with ease.
3. Easy to Use:
User-friendly design makes crimping hoses a breeze. With simple operating mechanisms, you can quickly achieve professional-grade results without the need for complicated setups or external power sources. Master the art of hose crimping effortlessly!
TECHNICAL DATA
| Model | P16 Portable Hose Press |
| Crimping Range | 14 - 47 (mm) |
| Crimping Force | 150 (T) |
| Hose Size | 1/4 - 1 (inch) |
| Max. Opening | 20 (mm) |
| Die Sets | 7 |
| Die Set Type | P16 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | MS |
| Standard Voltage |
Manual Pump |
| Motor Power | Manual Pump |
| Length | 400 (mm) |
| Width | 320 (mm) |
| Height | 300 (mm) |
| Weight | 32 (KG) |
P16 HOSE PRESSING MACHINE DIE SETS
| Die No. | Crimping Range | Length |
| 6* | 6 - 8 mm | 55 |
| 8* | 8 - 10 mm | 55 |
| 10* | 10 - 12 mm | 55 |
| 12* | 12 - 14 mm | 55 |
| 14 | 14 - 16 mm | 55 |
| 16 | 16 - 19 mm | 55 |
| 19 | 19 - 23 mm | 55 |
| 23 | 23 - 27 mm | 55 |
| 27 | 27 - 31 mm | 55 |
| 31 | 31 - 35 mm | 65 |
| 35 | 35 - 41 mm | 65 |
NOTE
- * for non standard die sets;
- Customized die sets are available;
- Max. opening is the stroke between die sets fully closed and fully opened.
OPTIONAL
- Quick Change Tool
- Quick Change Die Set Rack;
- UC control;
P16 HDYARULIC CRIMPING MACHINE APPLICATIONS
-
CReliable quality, easy to use, a great helper for starting a business.
-
GThose who open a truck repair shop usually apply pressure to the brake oil pipe and hydraulic oil pipe of the truck. The manual version has sufficient pressure and the joint is tightly pressed. The truck runs long distances without oil leakage, which is recognized by the driver. The machine is durable and can be used in stores, as well as in places without electricity outdoors
-
2As a shop specializing in precision machinery, we have exceptionally high precision requirements for crimping machines. This equipment features adjustable crimping stroke with minimal error, ensuring oil-free connections after crimping. Even beginners can quickly learn—just 30 minutes of training enables them to operate it independently
