Specifications
Highlight:
2 Inch Hose Crimping Machine
,Hydraulic Pressing Hose Crimping Machine
,P32 Hose Crimping Machine
Crimping Range:
14 - 87mm
Hose Size:
1/4 - 2.5inch
Die Sets:
13
Color:
Blue
Max. Opening:
31mm
Crimping Force:
650T
System Pressure:
31.5Mpa
Voltage:
380V
Size:
650*550*1360mm
Weight:
310Kg
Key Attributes
Brand Name:
MENSION
Model Number:
MS-P32N
Place of Origin:
CN
Certification:
CE RoHS
Minimum Order Quantity:
1 Set
Price:
Contact Us
Supply Ability:
1000 Sets Per Month
Delivery Time:
2 - 7 Working Days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Standard Packaging:
One Plywood For One Set
Product Description
P32N Numerical Control Hose Crimping Machine
The P32N hose crimper is a Finn Power type numerical control hose crimping machine that automates the crimping process with precision. Utilizing advanced numerical control technology, it delivers accurate and consistent crimps while eliminating variations to ensure reliable hydraulic connections.
Key Features
- High precision crimping with 0.01mm accuracy
- High efficiency for mass hose production
- Easy to operate with user-friendly controls
- Quick mold change capability
- Integrated safety features for operator protection
- Versatile handling of various hose sizes and configurations
Technical Specifications
| Model | P32N Hose Pressing Machine |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 650 (T) |
| Hose Size | 1/4 - 2.5 (inch) |
| Max. Opening | 31 (mm) |
| Die Sets | 13 |
| Die Set Type | P32 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | UC |
| Standard Voltage | 380 (V) |
| Motor Power | 3.75 (KW) |
| Dimensions (L*W*H) | 650 * 550 * 1360 (mm) |
| Weight | 310 (KG) |
P32 Crimper Die Sets
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8mm | 55 |
| 8* | 8 - 10mm | 55 |
| 10* | 10 - 12mm | 55 |
| 12* | 12 - 14mm | 55 |
| 14 | 14 - 16mm | 55 |
| 16 | 16 - 19mm | 55 |
| 19 | 19 - 22mm | 55 |
| 22 | 22 - 26mm | 70 |
| 26 | 26 - 30mm | 70 |
| 30 | 30 - 34mm | 70 |
| 34 | 34 - 39mm | 75 |
| 39 | 39 - 45mm | 75 |
| 45 | 45 - 51mm | 90 |
| 51 | 51 - 57mm | 90 |
| 57 | 57 - 63mm | 100 |
| 63 | 63 - 69mm | 110 |
| 69 | 69 - 78mm | 110 |
* Non-standard die sets
Customized die sets available
Special voltages available: 110V, 208V, 240V, 415V
Customized die sets available
Special voltages available: 110V, 208V, 240V, 415V
Industry Applications
Hose crimping machines are essential tools across multiple industries where secure and reliable hose connections are critical for fluid transfer systems.
Primary Application Fields
- Manufacturing & Industrial: Automotive, aerospace, machinery, and equipment production for hydraulic systems, pneumatic systems, and fluid transfer applications
- Construction & Infrastructure: Concrete pumping, foundation work, tunneling, and heavy-duty construction equipment requiring secure fluid connections
- Agriculture & Farming: Irrigation systems, sprayers, fertilizers, and farming equipment for efficient fluid distribution
- Oil & Gas: Drilling operations, offshore platforms, oil refineries, and pipelines in demanding petroleum applications
- Transportation & Automotive: Vehicle fuel lines, brake systems, and fluid-carrying applications in cars, trucks, buses, and specialized vehicles
- Marine & Shipbuilding: Shipbuilding, offshore vessels, and maritime equipment for hydraulic systems, fuel lines, and cooling systems
